ZVF 25 with EKG and GKG

Manual nozzle DN 25 for aircraft overwing refuelling, with ground cable assembly, dust cap assembly. NEW: free of non-ferrous metals to JIG rules. Note: yellow chrome plating on swivel is 'free or non-ferrous metal'.

DCC Dry Cryogenic Coupling for LNG

with cap

MannTek DDC-V 150 F Al, DDC-M 150-6"

Rubber Expansion Joint ERP 80.16

RED SPOT expansion joints for sanitary installations, highly flexible, for cold and warm water, pool water, sea water, drinking water. Temperature range (depending on medium) - 40° C up to + 90° C, temporarily up to + 120° C. Electrically dissipative.

Camlock cam locking couplings:

Attachment AVB dust plug with chain to Spannloc clamps (service free of charge)

AN Rd 78 SS

Welding nipple with foodstuff thread, stainless steel

AN 2 SS

Welding nipple stainless steel

DAC-V 65, DAC-M 65

Coupling test facility

MK 80-90 SS; MK coupling stainless steel with bent lever 90°

TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

KR 50 - 21/2"

Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors

ELAFLEX Hamburg

Assembling Spannfix hose clamps

Elaflon PTFE

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

Fuel Grade Identification to EN 16942 for ZVA Nozzles

Type EK FGI - attach with Product Badge EK 145

ELAPAC FD 50 Oval flange seal

Hoses for Liquefied Petroleum Gas / Autogas

LPG 13, LPG 16 black/orange, LPG 19

UTS 200 hose assembly in chemical plant

Italy

Tecnopal chemicol hose assembly

on hose reel

UTS 50 hose assembly

with MannTek DDC Dry Disconnect Coupling; use eg. as road tanker hose for filling AdBlue^® petrol station tanks

Elaflon Plus FEP 25

Universal hose ELAFLON PLUS FEP with seamless FEP lining, resistant to all commonly used chemicals, see resistance chart. Suitable for both suction and delivery (Type FEP D = delivery only). W.P. up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° C up to + 100° C, briefly up to 130° C. Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min (open system). Meets EN 12115.

Rubber Expansion Joint ERV-OR 80.25

ORANGE BAND expansion joints for Liquid Petroleum Gas (LPG) to EN 589. For tank trucks and refuelling stations. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically dissipative.

ERV-R 150.16 ZS 2

Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

DDC-V 50 SS

MannTek Dry Disconnect Coupling, DN 50, stainless steel, with BSP thread connection

PAL hoses for the chemical industry

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings; Use of adapters with ACME thread

DAC-V 65, DAC-M 65

Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - in action

Oasis DMI Dispenser Manifold for CNG

Hose assemblies

for saturated steam, chemicals, petroleum based products

V 16-3/4"

Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, red.

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

Universal hose assembly UTS 50 with VC 50 SS / SS
