Media Library / Images

ERV-G Yellow Band rubber expansion joint, exhaust sytem of a yacht

HD 10 C sensing hose

Use as sensing hose for aircraft dispensers (hydrant dispensers)

Oasis SV104 Sandwich Valve with Air Torque Actuator, for CNG

HD-C, aircraft refueller

ERV-CR 100 (4")

'CR' Rubber Expansion Joint for cold and warm water / ship engine room

Hose Reel spring rewind red, SL 19 black, ZVA Slimline 2 green

FFC 50.16 SS

Fixed flange hose fitting of stainless steel, with Spannloc clamps

Alternative fuels: DME Dimethyl Ester

DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly

Slimline 21 blue

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

Offset UST filling point, LTW hose assemblies with TW couplings

ERV VSRV:

ERV with bolted vacuum support ring. For maximal vacuum resistance of the selected ERV. Bolted ring in stainless steel AISI 316 Ti.

Equipment truck for dangerous goods accidents, Elaflon PTFE universal hose assembly, DDC Dry Disconnect Coupling

Aljac bonding reel

Airfield refueller

Dispenser picture to distinguish the three different kinds of Safety Breaks

Hose Break, Pump Break, Nozzle Break

EL 800 Earthing Strap with vulcanized copper strand

Electrically conductive bonding. Use for road tankers for petroleum based products, solvents, bulk tankers, forklifts, cable cars and cable Electro-Buses.

Rubber Expansion Joint ERV-R 80.16

RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

Production plastic precision parts

Ship loading with chemicals

UTS 150 hose assembly, ARK-S Safety Break Coupling

Alternative fuels: HVO (hydrotreated vegetable oil) and E 85 (gasoline with up to 85% ethanol)

ZVA Slimline 2, ZVA Slimline 2 GR

DDC-M 50 F Aseptic

MannTek Dry Disconnect Coupling with Aseptic flange

Heating oil delivery: ZH 50 nozzle, HD reel hose

ZVA Slimline 2 nozzles special version, Slimline dispensing hoses blue / red

Thailand

ElaSil ELS 38 with DIN 11851 hose fitting, FREE OF DEAD SPACES

Rail tanker unloading of petroleum based products

FWS PP St/St composite hose, MannTek Dry Disconnect Coupling, KWZ adapter

ERV-G, DN 250 and DN 300

Yellow Band

Locomotive refuelling

DDC-V Dry Disconnect Coupling (filler inlet of the locomotive), DDC-K cap

Slimline SF 19 black

Quality petrol pump hose for gasoline and diesel fuels. Special type 'sulphur-free'. Sulphur content of fuel does not increase, even if medium remains with the hose for a longer time, see Information 12. 15 and catalogue page 111c.

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

L.P.Gas petrolstation, GG20, Slimline, ZVG 2 EURO UL

Rubber Expansion Joint ERV-GS HNBR 80.16

YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.
