GW-G, FGN 4" SS, RS 4" x 3" SS, MK 80 SS

f. fire brigade dangerous goods equipment trucks

ROTEX 80.16

Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative

Ship loading with chemicals

UTS 150 hose assembly, ARK-S Safety Break Coupling

Camlock cam locking couplings

top left – ELAFLEX standard version; bottom right – ELAFLEX EASYLOC version

Rail tanker unloading of petroleum based products

with FWS 80 PP St/St composite hoses and MannTek Dry Disconnect Couplings

ERV-GS

"Yellow Steel" Rubber Expansion Joints / ship engine room of a ferry

GasGuard LPG nozzle GG20DN

With long connector nut to access 'hard to reach' fill points. "DN": suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure : 1,7 cm³.

Compact Line HD 50, Hose Reel Spring Rewind

FEP 5O, MannTek DDC-M 5O SS

HD-C, ZVF 50, Refueller

Aircraft refueller, overwing refuelling JET

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components (English)

ZVA Slimline 2 GR, Coax hose assembly

Automatic nozzle with vapour recovery, flowrate up to 45 l / min.

Unloading chemical road tanker

Tecnopal hose assembly, DDC Dry Disconnect Coupling, Guillemin adapter

Vehicle refuelling Korea with LPG (L.P. Gas, Autogas, Propane)

ZVG 2 K nozzle, LPG 16 hose assembly

Slimline 16 yellow

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

Hose Assemblies with Flange - Elapac seals

On board of an aircraft refueller: TW-hose, Spannloc flanged coupling; flange seal: Elapac.

Rail tanker unloading of petroleum based products

LTW 75 (hose), MKX 75 ('TW' female coupler with Spannfix clamps), Adapter KWZ x VK 80 (51/2" x 'TW'-male coupler)

Underwing refuelling

Biofuel

DCC Dry Cryogenic Coupling for LNG

ERV-G AF

Suitable for piping systems of aviation refuelling or dispensing vehicles in accordance to EN ISO 1825/EI 1529. Suitable for all aviation fuels.

ERV-G 80.TW

Yellow Band rubber expansion joint with TW flanges

Unloading chemical road tanker

Elaflon PTFE hose assembly, TW couplings

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapter for Rail Tanker 51/2" connection KWZ SS/Vi x VK 50 SS/Vi

ZVF 50 AVGAS for aircraft refuelling

with ER 583

ZVA Slimline 2, black, guard 3 - detail view with new hold-open latch

Urea solution for cars and light transporters: ZVA LV for AdBlue® nozzle

ELAFLEX Hamburg

Assembling Spannloc hose clamps

ERV VSRV:

ERV with bolted vacuum support ring. For maximal vacuum resistance of the selected ERV. Bolted ring in stainless steel AISI 316 Ti.

MB 80 SSE

TW dust cap of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Fluorflex FXD universal hose assemblies

with inner corrugation for maximal flexibility. Picture 2

Swivel EA 075 A f. ZVA HV for AdBlue®

new design
