Polypal Clean hose assembly
Pharmaceutical production
ZVA Slimline 2 nozzles special version, Slimline dispensing hoses blue / red
Thailand
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO (UL listed)
ElaSil® Silicone hose assemblies DN 13-102
For for high media purity requirements, easy to clean. Suitable for Pharma, foodstuff and cosmetics industry. Homogeneous hose construction of platinum cured, translucent and phtalate free Silicone (FDA / USP), resistant to kinking and highly flexible. Large temperature range -60° C to +200° C. Available as complete hose assembly with crimped fittings, DN 13 to 102. Here: DN 25 with Camlock Cam Locking Coupling and Triclamp connection
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (German)
ZVA 25 with red scuffguard and Slimline hose assembly
HIFLO-Automatic nozzle DN 25 (1"), flowrate up to 140 litres/min.
SSB 16 LV
Safety Swivel Break, for ZVA LV for AdBlue®. Calibration switch 10 l/min – 5 l/min
ELAFLEX Hamburg
Manufacturing bronze corrugated pipes
TGN 2" Al (TGN 50 Al)
Tank truck flange aluminium, one end flange to DIN 28462, other end male BSP thread.
ELAFLEX Hamburg
Visual quality checks
Overview "From terminal to nozzle"
ZVA 25 for aircraft refuelling
red plastic cover (scuffguard), decal (sticker) AVGAS, dust cap and ground cable assembly
Production MannTek, Sweden
ZVA Slimline 2 with reduced spout and Slimline hose
here: for gasoline, use in countries without vapour recovery regulation
ContiTech Production ERV
In production testing, rubberized fabric
ZVA Slimline 2 and ZVA Slimline 2 GR, Slimline hose assemblies
Petrol station, Germany
ZVF 50 PTL (Push-Twist-Lock), strainer inspection
SPANNFIX pinned Sicherheits Klemmbacken aus stainless steel
SX 75 SS
V 16-3/4"
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, blue.
Nozzles and hose assemblies for L.P. Gas (LPG, Autogas)
Chains K 160, K 160 SS, K 180 L, K 200, K 200 SS, K 260 L, K 300, K 300 SS, K 360, K 360 SS
Connection between coupling and dust cap / plug
ZVA-RG
Automatic nozzle ZVA DN 19, of red bronze (gunmetal), for solvents and corrosive media. Flowrate up to 60 l / min.
L.P.Gas home delivery:
LPG 38 hose assembly - Aboveground storage Tank
ELAFLEX Hamburg
Nozzle stock, ZVG 2 DISH
Filling of chemicals with nozzles
UTS hose assemblies, ZVA TD nozzles special type for chemicals
Terminal / gantry: 'Polypal Oil 100' and 'TW 100' hose assemblies for bottom loading of road tankers
LBS 50 foodstuff hose, RMC 50 SS foodstuff fitting with Spannloc of stainless steel
Aseptic bulk filling
ELAPHARM and Tecnopal hose assemblies
HD-C Neon, large reel, VK 100 Ms, MB 100 Al
