Media Library / Images

Bunker boat: FHD flat laying hoses, HD hoses

TGN 2" Al (TGN 50 Al)

Tank truck flange aluminium, one end flange to DIN 28462, other end male BSP thread.

Ultra Fast Fill Quick Coupler 350 bar

for Hydrogen

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose

Heating oil delivery: ZV 500 nozzle, HD reel hose - up to 80 mtr length

oasis TH104 Tank Head Valves, CNG trailer

Hose Reel Spring Rewind, ZVA Slimline 2 blue

ZVA Slimline 2 GR, black, guard 3 - bottom view

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Sand casting

AN 2 SS

Welding nipple stainless steel

ERV SR:

ERV with inner protection sleeve of stainless steel AISI 316 Ti to prevent abrasion of the rubber liner, i. e. for media containing abrasive components or to avoid cavitation. Please note : The nominal bore is reduced.

Universal hose UTD 38

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapters Storz / Guillemin Storz C SS/Vi x VK 50 SS/Vi, Storz C SS/Vi x MK 50 SS/Vi, GK 50 SS/Vi x VK 50 SS/Vi, GK 80 SS/Vi x VK 50 SS/Vi

ZVG 2 ACME nozzle for L.P. Gas / Autogas

LPG nozzle for vehicle refuelling with liquefied petroleum gas (propane, butane and mixtures) up to 50 l / min. Working pressure 25 bar. Test pressure 40 bar. Burst pressure > 100 bar. Temperature range - 25° up to + 70° C, 'LT'-Type down to - 40° C.

ERV-G

Pump station for fuels

DAC-V 65, DAC-M 65

Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - in action

Universal hose assembly UTL 63 with VC 63-3" SS / SS and MK-A 80 SS

ZVF 25 for aircraft refuelling

dust cap and ground cable assembly

MK-A 80 SS

MK 80 SS with active safeguard lever

Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)

PHD 100, airport depot

GasGuard LPG nozzle GG1E

eoconomic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.

VB 100 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

SG 1" 1x0 Al

Sight Glass with propeller, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.

CNG Safety Break

SB-CNG FLVL-S

ELAPHARM Type EPH-OHM G

electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner. Clamp fittings, lining flared (free of dead spaces).

EA 866 scuffguard: fuel grade identification 'LPG' to standard

The scuffguard for LPG / Autogas nozzles shows the LPG fuel grade marking required by standard, and offers a large advertising space

ELAFLEX Hamburg, narrow aisle stock for small parts

H2 Hydrogen

ERV-H2+ PN 25, DN 80 und DN 100

ZVG 2 ACME nozzle for L.P. Gas / Autogas

visible: Magnet within the guard for the dispenser Reed Switch
