Media Library / Images

ELAFLEX Hamburg

Assembling bunker hose

ZVF 25 for aircraft refuelling

dust cap and ground cable assembly

Hose assemblies and Rubber Expansion Joints for the chemical industry

ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad

Oasis DMI Dispenser Manifold for CNG

Rubber Expansion Joint ERV-W 80.16

WHITE BAND expansion joints for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.

SG 80-TW1 Al

Sight glass with rods, with TW flanges to DIN 28460

AKD-Hy

Coupling seal type AKD for cam locking couplings EN 14420-7. Here: of CSM

Fire-resistant cover for hoses

Dispenser picture to distinguish the three different kinds of Safety Breaks

Hose Break, Pump Break, Nozzle Break

M 19-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 19 SF hose Sulfur Free, black.

ZH 50.2

High performance manual operated dispensing nozzle, for Diesel, heating oil, viscous gear and motor oils, max. flowrate 450 litres/min.

ERV Rubber Expansion Joints with different flange types / flange materials

ZVA Slimline 2, guard no. 8D, black scuffguard, red product sleeve, SL 16 hose assembly with red colour sleeve

TSG 3" Rg

tank truck sight glass type TSG 3", one end TW tank truck fl ange according to DIN 28459, other end male thread

Road tanker with hose reel spring rewind blue, ZVA Slimline 2 green

Mobile refuelling

ZVF 50 UL 91 / green

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.

ERV-R 150.16 ZS 2

Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

Marking of High Temperature Types ZVA Slimline 2 / ZVA Slimline 2 GR

For regions with exceptionally hot summer conditions which may lead to particularly high fuel temperatures we offer High Temperature (HT) nozzle types, available for ZVA Slimline 2 and ZVA Slimline 2 GR.

Fuel delivery at the petrol station

LTW 75 fuel delivery hose, MKX 80 female TW coupler

Motorcycle refuelling at the petrol station

ZVA Slimline 2 GR, Germany

ZVA Slimline 2 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

Rubber Expansion Joint ERV-BR 80.16

BR Expansion Joints, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products (e. g. carbon-blacks). Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e.g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR

Equipment truck for dangerous goods accidents

suitable hose assemblies and adapters from Elaflex, ELAFLEX_Information_2.17E.pdf

LNG Refuelling

N-LNG Nozzle, push handles to couple

Aircraft refuelling hoses

VHD-C NEON, SFC TW, HD-C NEON, MC SS Al, PHD-F, VC SS Al

Oasis HC308 Ultra Fast Quick Fill Coupler, SAE male, for CNG

ZVA Slimline 2 GR, CSB 21, SL 21 Coax

petrol station Dubai - Vapour Recovery

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

PSB Pump Safety Break for High Hose Dispensers

Picture shows separation of the Slimline hose assembly after a drive-off accident

DG 50 Al - new Aluminium swivel for ZVF 50

Section view
