Ship loading with chemicals
UTS 150 hose assembly, ARK-S Safety Break Coupling
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
Production plastic parts
Injection Molding
Quality in the detail: valve assembly of a ZVA Slimline 2 petrol station nozzle
DDC-M 100, TW hose assembly
Rail tanker bottom loading with Dry Disconnect Coupling
Hose Reel with manual rewind blue, TW 100, DDC-M 100 SS
Marine terminal, with grey cabinet, customised
Elaflex hose assemblies and Rubber Expansion Joints
TW coupler MK 80 SS-90° (bent lever) and dust plug VB 80 ADR SS with pressure relief
HD 100 C, hydrant hose
Aircraft dispenser, pit
Ultra Fast Fill Quick Coupler 350 bar
for Hydrogen
Elaflex Hamburg, narrow aisle stock for small parts
ERV-R 200x175.16 ZS 4
Red Band Rubber Expansion Joint, special length 175 mm, with "ZS" limiter (tie rods with outer limitation in rubber bushings)
ERV-GR Green Band rubber expansion joint, Biogas entergy plant
ERV-GR 80.16
GREEN BAND Rubber Expansion Joint for chemicals, acids, alkalis and aggressive chemical waste water. For oil-contaminated compressed air up to + 90° C. Temperature range (depending on medium) - 20° C up to + 100° C, temporarily up to + 110° C. Electrically non-conductive.
ERV-R 150.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
SPANNLOC bolted safety clamps of aus stainless steel
SC 75 SS
Urea solution for cars and light transporters: ZVA AdBlue LV nozzle
Hose Beads
BD 50, BD 63
ERV VSD:
ERV with vacuum support spiral. Spiral of AISI 316 Ti, used when the vacuum resistance of the chosen ERV is not sufficient.
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
GasGuard LPG nozzles
GG1E, GG1DN, GG20H, GG30
ELAPHARM Type EPH-OHM G
electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner. Clamp fittings, lining flared (free of dead spaces).
KW bronze corrugated pipe with cathodic protection
Cathodic protection flexible pipe connector (bronze corrugated pipe) for electrically insulating, cathodically protected installations. Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps - and directly underneath the dispensers
Easy Rotating Safety Swivel Break, Type 'ERS'
SSB 16 ERS
L.P.Gas petrolstation, GG20, Slimline, ZVG 2 EURO UL
Oasis FM104 Fuel Manifold on Natural Gas powered vehicle
From Terminal To Nozzle
Elaflex refuelling equipment
ZVA Slimline 2 and ZVA Slimline 2 GR, Slimline hose assemblies
Petrol station, Indonesia
Tank container filling coupling: MK 80-32 SS with VB 80 SS
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
