VC 65-21/2" SS / SS
Spannloc threaded hose coupling with BSP male thread / Spannloc of stainless steel
VKC 75.80 SS
TW male hose coupling, stainless steel, two part, with Spannloc clamps
ELAFLEX Hamburg
Assembling dispensing hose fitting
AN 2 Al
Welding nipple aluminium
AdBlue® urea solution, road tanker:
DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel
ZV 500 for chemials
Bulk filling of Methylene Chloride
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Plettenberg factory 1
ELAFLEX Hamburg
Safety Swivel Break SSB 16 SS of stainless steel f. ZVA HV for AdBlue®
old design
Unloading Methanol
with FWS composite hose, DDC Dry Disconnect Coupling
Rubber Expansion Joint ERV-GS 80.16
YELLOW STEEL expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Temperature (depending on medium) range - 20° C up to + 90° C, temporarily up to + 100° C. Fire resistant (to ISO 15540) up to 30 min. and 800° C. Electrically dissipative.
ERV-ROTEX expansion joint, inhouse emergency power generator
Offshore FSRU (Floating Regasification Unit), connector for gasoil sludge / seawater
DDC-V 150 F
SX 75
Spannfix clamp DN 75 of aluminium
Slimline 19 black
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
Helicopter refuelling winter / Canada
ZVF 50, HD 50 C NEON
Ship bunkering with LNG
CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media
ZVG 2 K (Korea)
with EA 866 scuffguard / nozzle talker
ELAFLEX Hamburg
Manufacturing bronze corrugated pipes
Offshore FSRU (Floating Regasification Unit), connector for gasoil sludge / seawater
DDC-V 150 F
DAC-M 65
MannTek Dry Aviation Coupling
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 18
MC 100 SS female threaded hose coupling with Spannloc clamps
with universal hose UTL 100
KWZ 3" Al
Rail tanker adapter with male thread connection, aluminium
Manifold, Ultra Fast Fill Quick Coupler 350 bar
for Hydrogen
ZVA Slimline 2 yellow / red / blue with SSB 16 Safety Break
Stainless steel couplings with PFA coating, type "...SSE"
Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
Camlock Cam Locking hose tail AMK-St 50 Ms (brass)
for the assembling with Spannfix or Spannloc clamps
Group picture
TW 100, DDC-M100 4", Hose Reel VR Spring Rewind System, ZVA Slimline 2 GR, ERV-G 1000, ERV-BR 300
