Universal hose UTL 38
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
Universal hose UTD 38
UTS hose assembly with AMKC 32 SS and AVKC 32 SS
'Camlock' stainless steel female and male coupling to EN 14420 - 7 with hose tail and Spannloc clamps
ELAFIX 40 Anti-Siphon
Magnet adapter for installation in filler necks from DN 40. This adapter allows the refilling of urea solution with ZVA HV for AdBlue®, without the risk of misfillings. Meets ISO 22241-4. – Version with anti-theft protection –
Offshore Methane gas production
UTS / CHS hose assemblies
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (German)
Tecnopal chemicol hose assembly
on hose reel
ELAFLEX Hamburg
CAD construction
ElaSil® Silicone hose assemblies DN 13-102
For Pharma, foodstuff and cosmetics industry.
ELS 25 with Camlock Cam Locking Coupling, foodstuff thread and Triclamp.
VC 75-3" SS / SS
Spannloc threaded hose coupling with BSP male thread / Spannloc of stainless steel
Storz Safety Coupling SHK
upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.
Oasis FV103 Fill Valve, CNG service station
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Development
DDC-M 100, TW hose assembly
Rail tanker bottom loading with Dry Disconnect Coupling
ELAFLEX Hamburg
Manufacturing bronze corrugated pipes
MK 80-90 SS; MK coupling stainless steel with bent lever 90°
TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
Type PCS, Polypal Clean
PCS 25, PCS 63, PCS 100
M 16-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, blue.
Simultaneous Refuelling/Filling of Diesel and AdBlue®
Picture 1
Nozzle boot NB-ZVF 50
for ZVF 50 Oberflügel-Zapfventile
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 24
ZVA Slimline 2 nozzles with splashguard, Slimline hose assemblies
Refuelling at a petrol station in the United Arab Emirates
Unloading: MK couplers with DDC-V 80 adapter
ZV 500 for chemials
Bulk filling of Methylene Chloride
Refuelling equipment for petroleum based products:
Elaflex "Yellow Band" Hose assemblies, ERV Rubber Expansion Joints
Slimline SF 19 black
Quality petrol pump hose for gasoline and diesel fuels. Special type 'sulphur-free'. Sulphur content of fuel does not increase, even if medium remains with the hose for a longer time, see Information 12. 15 and catalogue page 111c.
ELAFLEX refuelling equipment for LPG (Autogas, L.P.Gas)
Cargo loading of ship - various media
FWS composite hoses
DDC-V 80 F
Dry Disconnect Coupling for Epoxi resin loading - with sensor
