Media Library / Images

ZVF 50 UL for aircraft refuelling with ER 494

EA 909 green, EK 946 green

Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling

FSH flame protection cover for ERV rubber expansion joints

Use e.g. in ship engine rooms

M 19-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 19 SF hose Sulfur Free, black.

Nozzle boot NB-ZVF 50

for ZVF 50 Oberflügel-Zapfventile

VB 50 P, VB 80 P

TW dust plugs of Polyamide

Storz Safety Coupling SHK

upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.

Production TW couplings

Lube oil plant: manifold with DDC-V Dry Disconnect Couplings

HD 38 C, VX 38 - 11/2 Sn

Hose assembly for aircraft refuelling, fitting in contact with medium tin plated

Elaflex hoses

SD, PTFE, LPG, TW, FEP, SL

Accessories and spare parts: Ground cable assembly, dust cap assemblies, spouts, strainer

ER 339, ER 494, ER 495, ER 587 JET PTL, EKG 1200, GKG 19, GKG 32, GKG 38-J, ES336.1

AN 2 Al

Welding nipple aluminium

HD-C aircraft refuelling hose

TW 75 E

SG-COAX_Al

Sight Glass, to EN 13617-1, for ZVA Slimline 2 GR with vapour recovery. Installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised fuels.

ELAFLEX Hamburg

ERV, assembling limiters (tie rods) with rubber bushings

MB 100 Al

Dust cap for VK 100, aluminium

AMK-St 38 SSE

Camlock female coupler, hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Production Picture 22

M 21-1" cr

Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, green.

M 16-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, yellow.

Stainless steel Hose Reel spring rewind black, FEP 38, DDC-M 50 SS

SFC 38 SSE

Swiveling flange hose coupling with Spannfix clamps. Material: stainless steel with universally resistant PFA coating (red)

NB-ZVF 50 SR, ER 583 PTL, HD-C 38

Nozzle boot f. ZVF 50 with additional spout retainer

Slimline 16 yellow

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

FGN 2 St

Flange with male thread, steel zinc plated/chromated

Flexible bronze pipe connectors

Installed in suction pipe between dispenser and underground storage tank

ZVA Slimline 2

Automatic nozzle DN 19, for flowrate max. 80 l / min. Product Sleeve EK 043 blue, Slimline dispensing hose assembly

Slimline quality dispensing hose for the forecourt

Slimline 19 black

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
