ZVA_AdBlue_LV_2-Stufen-Anschlag_Step1

Use - 1/2

Ship sided connectors for bunkeringof fuel, lube oils, fresh water; unloading of sewage

DDC Dry Disconnect Couplings with caps

ERV-G 1000

'Yellow Band' Rubber Expansion Joint - for petroleum based products

Oasis FV103 45° Fill Valve with NC 203 P30 Nozzle, for CNG

ZVA Slimline 2 with reduced spout and Slimline hose

here: for gasoline, use in countries without vapour recovery regulation

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components (German)

BD 63, HD 63 C

Aircraft refuelling hoses with ELAFLEX Hose Beads 'BD'. Details see Information 7.17

Ship bunkering

FHD hose assemblies

Unloading petroleum products at the service station (road tanker to UST)

Connection offset UST filling point: LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance

Rail tanker unloading of petroleum based products

Plant side: FWS PP St/St composite hoses, SG 3" Sight Glasses

ZVA LV for AdBlue® with SSB 16 LV SL 16 for AdBlue® hose assembly (blue)

Hoses for Liquefied Petroleum Gas / Autogas

LPG 13, LPG 16 black/orange, LPG 19

NB-ZVF 50 SR, ER 583 PTL, Aljac Closed Circuit Sampler (CCS)

Nozzle boot f. ZVF 50 with additional spout retainer

Solvapal hose assemblies

Solvents

GasGuard LPG nozzle GG20

With long connector nut to access 'hard to reach' fill points. Economic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.

Hose assemblies for the chemical industry

ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad

Rubber Expansion Joint ERV-GS 80.16

YELLOW STEEL expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Temperature (depending on medium) range - 20° C up to + 90° C, temporarily up to + 100° C. Fire resistant (to ISO 15540) up to 30 min. and 800° C. Electrically dissipative.

ZVA Slimline 2, guard 3, black scuffguard, blue colour sleeve

SPANNFIX pinned safety clamps of aluminium

SX 50 NR Al

SG 1 1x0 SS for Nozzles for AdBlue®

Attach on dispenser side of swivel

ERV-R 150.16 ZS 2

Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

MK-A 80 SS, TW female coupler with Active Safeguard Lever

connected: hose assembly with VKX 75.80 SS

Heating oil delivery: ZV 500 nozzle, HD reel hose - up to 80 mtr length

ELAFLEX Hamburg

Manufacturing bronze corrugated pipes

Tank container, Antarctica: HD-LT hose assembly, ZVF 25 LT nozzle

Low Temperature types

SMS 19-3/4"

Steam hose couplings of steel to EN 14423. With bolted clamps of hot stamped brass. For saturated steam hoses up to 220° C, compressed air, oxygen, oils up to 25 bar W.P. Hose tail and union nut of steel Zn / Cr.

SG 1" 1x0 Al

Sight Glass, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.

Boat refuelling

ZVA Slimline 25, HD hose assembly

ZVA 25 spout with stainless steel tip

SMX 50-2"

Female hose coupling of steel with Spannfix clamps
