Media Library / Images
In order to send you the picture material you need, please click some examples - after receipt of your E-Mail we will personally contact you to hear your exact requirements.
Category
- All
- Products
- Applications
- Company
Applications
- All
- Petrol Station Equipment
- AdBlue® Refilling
- Tank Truck Equipment
- Alternative Fuels
- Chemicals
- LPG / DME
- Pharmaceuticals
- CNG / NGV
- Aircraft Refuelling Equipment
- LNG
- Rail Tankers
- H2 Hydrogen
- Ships & Marina
- LH2 Hydrogen
- Rubber Expansion Joints
- Hose Reels
Sales Division
- All
- SAT(Hoses and Fittings)
- EHT(Petrol Pump Nozzles and Accessories / Hoses)
- ERV(Rubber Expansion Joints)
Sorting
- Newest on top
- Alphabetical
Filter by keyword
CHS 50
Lilac Band chemical hose with helix, DN 50
Railtanker
MannTek DDC-V 80 F Dry Disconnect Couplings (tank unit with flange), Pressure Caps PN 25 with pressure relief
DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75, DDC-K 3" SS ADR
Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose. DDC cap with pressure relief at container tank outlet.
Rail tanker discharge coupling KWK, with elbow DN 80
for damaged / dirty rail tanker or other threaded hose connections. Used e.g. for environmental protection trucks
ZV 500 DDC, ZVA 32 DDC, hose assembly with DDC-M coupling
Refuelling of construction site machines from the road tanker: only one hose reel, choose between two nozzles (ZV 500 for bulk, ZVA 32 automatic nozzle up to 200 l/min)
ERV-W 80.16 ZS 2
White Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
L.P.Gas road tanker, Hose Reel with LPG 50, MannTek DGC
DGC-M 50 SS, DGC-K
ZVG 2 ACME nozzle for L.P. Gas / Autogas
pulling lever and latching, possible with one hand
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
FF-St 80 SSE
Fixed flange hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
Road tanker Sweden
large reel with HD hose assembly, DDC-V (Dry Disconnect Coupling, tank unit) and DDC-K (caps)
IBC Hose Coupling MC 38-S 60 SS, MX 38-S 60 SS
direct connection to the standard outlet S 60 of IBC
Vergleich visibility aircraft refuelling hoses - below: "Yellow Band" standard, top: "NEON" new version with reflecting bands
ZVF 50 JET overwing refuelling
with HD-C hose assembly
Elaflex Hamburg
Hose stock
ZVA Slimline 2 / ZVA Slimline 2 GR
HD 100 C, hydrant hose
Aircraft dispenser, pit
MK 50 SSE
TW female coupler. Material: stainless steel with universally resistant PFA coating (red)
Elaflon Plus FEP hose assembly, FFC-SS fixed hose flange
SFC 38 SSE
Swiveling flange hose coupling with Spannfix clamps. Material: stainless steel with universally resistant PFA coating (red)
Section view ERV-R Rubber Expansion Joint
FFBV 80, DAC-V 65, DAC-K 2 1/2" Al
MannTek Full Flow Ballvalves (FFBV), one way
Oasis FV103 Fill Valve, CNG dispenser
Hose assembly for petrol stations
COAX hose SL 21, with inner vapour hose, for vapour recovery Stage II
FWS composite hoses / hose assemblies
Type FWS PTFE with male threaded fitting, Type FWS PP with Camlock coupling, Type FWS VR with "TW" female coupler MK
ERV VSR:
ERV with vacuum support ring. Ring of AISI 316 Ti , used when the vacuum resistance of the chosen ERV is not sufficient.
KWZ x MK 80-32°
Rail car adapter with TW coupler, bent lever
Locomotive refuelling
DDC-V Dry Disconnect Coupling (filler inlet of the locomotive), DDC-K cap
Wear Advice
VHD 50
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
